Give yourself freedom with Velowave Ranger 2.0. Our electric bike is the perfect mix of style, power, and sustainability. It's a great way to get around and enjoy the best of the outdoors.
Built for the modern-day adventurer, the Velowave Ranger is the most versatile & powerful electric bike on the market today. With 40 miles by pedal (25 miles by throttle), a 7-level pedal sensor, a step-through frame, and a 7-speed shifter for smooth shifting, it's just what you need to be equipped for your next all-terrain adventure. Designed with a powerful 750w hub motor and a 48V 15Ah full-charge battery, this Ranger is equipped to take you on a journey from wherever you are to wherever you want to be!
The Velowave Ranger is an awesome electric step-through fat tire bike that's easy to use and makes a great partner for whatever adventure you care to undertake. You don't need technical mountain biking skills to be able to hit the trails with our thumb control throttle and comfortable seat pad. It's perfect if you're looking for a leisurely ride, an exercise ride, or something in between.
Ranger takes you to the next level. This bike is our most high-end model to date. A collection of all comfortable elements such as a step-through frame, and swept-back handlebars. With the addition of 26"*4.0" Kenda fat tires, the bike can ride effortlessly on all terrains. Pick your favorite color and make all your outdoor adventures possible today with the Velowave Ranger electric fat tire cruiser bike. *Bonus - comes with a free rear rack included!
Velowave Ranger 2.0 Step Thru 750W 48V Fat Tire Commuter Electric Bike Features:
- 750W Geared Hub Motor: Strong and powerful, providing strong electric power and making it stable to reach speed peaks. You can cruise around with little to no effort. Wait, climbing the hill, no problem.
- All Terrains Fat Tire: 26"*4.0" Fat Tire, anti-skidding, wear-resistant, adapt to snow, sand, and various terrains. The fat tire enables smooth riding on rugged landscapes means you can get more cycling experiences.
- Convenient Control: The convenient control system, multiple riding modes, hydraulic disc brake system, reliable and sensitive braking performance, and perfect braking experience.
- Removable LG Battery: Powered by a high-quality 48V 15AH LG battery, it covers 30-45 miles on a single charge. Conveniently lockable and removable, take it home or to the office for charging.
- Shimano 7-Speed Drivetrain: With Shimano 7-Speed drivetrain shifts smoothly, and helps you adjust the riding speed for different road sections and conditions. Enhance your riding experience. The more approachable handlebar is comfortable all the way.
- Safety: The Front & rear hydraulic disc brake system is very smooth and can play a good braking effect under any conditions. More suitable for people with less strength or beginners who can easily stop the e-bike with a light touch of the brake lever.
- Multifunctional Color Display: Provides power assist level, battery indicator, riding speed, and mileage data to help to better control your riding stats and achieve better exercise results. Thumb throttle control is also generally considered a safer option, especially for inexperienced riders.
- Comfortable Wide Saddle: We focus on details, and for a more comfortable riding experience, we choose a widened and enlarged comfortable seat pad.
Buyer Protection: We have an expert support staff. Should you feel dissatisfied, check out our. and reach out to us for any assistance
Velowave Ranger 2.0 Step Thru 750W 48V Fat Tire Commuter Electric Bike Specifications |
GENERAL | |
Classes | Class 3 (E-Bikes with a PAS only but receive motor assistance up to 28 miles/hour) |
Max Speed | 28 miles/hour by pedal, 20 miles/hour by throttle |
Range | Up to 90 Miles by Pedal; 30 Miles by Throttle(Calculation based on rider's weight of 75kg. Range varies according to road condition, weather, rider's weight, etc.) |
Pedal Assist | 5 Levels |
FRAMESET | |
Frame | 6061 Aluminium, Removable Battery, Internal Routing |
Fork | Hydraulic Suspension Fork with 60mm travel, with lockout |
WHEELS | |
Rim Material | Aluminum |
Rim Size | 26" 36H Front & Rear |
Front Wheel Spokes | 13G x 244/246mm, Black Stainless |
Rear Wheel Spokes | 12G x 217/219mm, Black Stainless |
Tubes | Butyl Rubber, Schrader Valve |
Hubs | Disc Nutted Front /Rear Axles |
Tire | Kenda Fat Tires |
Tire Size | 26" x 4.0" |
E-SYSTEM | |
Battery | Removable Internal Lithium-ion Battery, 48V 15Ah, 720Wh, LG Cells |
Charger | 48V 2 Amp Charger, Approx. 8 Hour Charging, Aviation Connector. UL LISTED |
Motor | Geared Hub Motor, Rated 750W, Peak 1000W, Max Torque 85NM |
Controller | 48V 25A Peak |
Display | Multifunctional Color-Screen Display |
Pedal Assist | Cadence Sensor |
Throttle | Thumb Throttle |
Front Light | 48V 10W LED Light, 30 LUX |
DRIVETRAIN | |
Shifter | Shimano 7-Speed RevoShift |
Rear Derailleur | Shimano ARDTY500D 7-Speed, Long Cage |
Crank & Chainring | 52T, 170mm Alloy Crank |
Freewheel | Shimano 14-28T, 7-Speed freewheel |
Pedal | Alloy Platform Pedals |
Chain | KMC 124 Link, 7-Speed |
COMPONENTS | |
Saddle | Comfortable Wide Saddle |
Seatpost | Forged Alloy, Ø30.4*350mm |
Seat Clamp | Ø35mm Quick Release |
Stem | Bar bore: Ø31.8mm, Clamp I.D.: Ø28.6mm, HEIGHT:70mm, RISE:±7° |
Handlebar | Aluminum Ø31.8mm, Width 720mm |
Headset | Sealed Bearing Headset |
Grips | Nylon Lock-on, Ergonomic Comfort |
Brake | Front & Rear Hydralic Disc Brakes, with180mm discs, with power-cut-off function |
Brake Rotor | 180mm, 1.9mm thick |
Kickstand | Side Kickstand, Alloy, Rear Mount |
Fenders | Plastic 26"x110mm |
Rear Rack | Aluminum Alloy Rear Rack |
WEIGHT | |
Net Weight | 34.9kg (76.94lb) ( including battery) |
Gross Weight | 45.6kg (100.53lb) |
Battery Weight | 4kg (8.82lb) |
Weight Limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
SIZE | |
Product Size | 1930x740x1210mm |
Packing Size | 1570x330x900mm |
Size and Fit
Handlebar Height | 1206mm |
Reach | 402mm |
Head Tube Length | 140mm |
Seat Tube Length | 17.8" |
Standover Height | 705mm |
Wheelbase | 1172mm |
Total Length | 1922mm |
Seat Height Min/Max | 819/1009mm |
Velowave E-Bikes come with a manufacturer's warranty against manufacturing defects and workmanship. Please click on the link for the Velowave warranty details.
